ACCU-SCOPE® EXS-210 Stereo Microscope Series

ACCU-SCOPE EXS-210 stereo microscope for inspection and laboratory work

GO TO:

ACCU-SCOPE's EXS-210 Series offers professional features for classroom applications or light industrial inspections at a reasonable price. The clean, crisp optics with variable LED illuminators sets a new standard in a compact "student-proof" stereo microscope. Features a built-in carrying handle and cordless operation.

Optical System

Fixed magnifications; Choose from: 1x/2x, 1x/3x, 2x/4x, 1x/2x/3x or 1x/2x/4x

Viewing Head

Binocular viewing head, inclined 45°, rotatable 360° and locked-in to prevent classroom tampering; interpupillary distance adjustment 54-76mm, diopter adjustment +/-5

Eyepieces

WF10x eyepiece, 20mm field of view. Eyepieces are locked-in.

Objectives

Fixed magnification objectives. Easily rotatable objective turret with finger grip allows for rapid and easy magnification change; objectives are parfocal and parcenter

Stage

59mm frosted glass stage plate in the base provides evenly diffused illumination; 59mm black and white contrast plate is also included

Condenser

N.A. 0.65 condenser with five aperture disc or iris diaphragm depending on the model.

Stand

Stable and sturdy cast alloy aluminum with an acid resistant finish on a dovetail stand with built-in handle for portability.

Illumination

Dual purpose illuminators can be switched on simultaneously or independently and provide illumination from above and/or below; rechargeable LED illuminators for corded or cordless operation provide illumination for 2 hours per charge (depending on lamp intensity set by the user); LED bulb temperature has a long lamp life of 20,000+ hours

Focusing System

Dual focusing knobs with adjustable tension control for rapid, effortless focusing

Accessories

Dust cover and instruction manual

Microscope Dimensions

7"W x 8-1/2"D x 11-3/4"H

Physical Weight

5lbs

Warranty

5 year limited warranty for parts, labor, and electronic components. 1 year warranty on LED bulb.
